Issue 1.2 UNIVERGE SV9100
5 - 30 Installing DT Series Digital and IP Multiline Terminals
3.1.4 ITL-8LD-1 (BK) TEL/ITL-8LD-1 (WH) TEL
This IP value Multiline Terminal has eight line keys with display and
is available in both black and white. The terminal features:
 Modular design
 Four step adjustable base
 Full-duplex speaker phone
 DESI-less line key displays eight lines per page (four pages of eight
lines available using scroll key)
 Protection button (lock)
 Seven color LED for incoming calls
 Two 224 X 96 full dot gray scale LCDs with cursor keys
 Backlit 10-key dial pad for easy viewing
 Full-duplex handsfree operation
 Wideband handset
 IEEE 802.3af compliant
 XML open interface
 10Base-T/100Base-TX network interface
 Backlit LCD
Figure 5-17 ITL-8LD-1 TEL
