Issue 1.2 UNIVERGE SV9100
5 - 56 Installing DT Series Digital and IP Multiline Terminals
10. Continue pressing Soft Key 4 to exit (Exit-Exit-Save). The
terminal will reset automatically.
4.6 Installing the Directory Card on the Multiline Terminal
A directory card can be attached to DT300/DT700 Series Multiline Terminals.
The directory card can be used to record often dialed numbers or other
important information.
1. After recording the information on the lined insert, reinsert it between the
plastic panels of the directory card. Attach the directory card to the
directory card holder as illustrated in Figure 5-47 Attaching Directory
Card to Directory Card Holder. Note that the open end slides into the
directory card holder.
2. Locate the two grooves on the top of the telephone as illustrated in
Figure 5-48 Attaching Directory Card Holder to the Multiline Terminal.
Push the directory card holder into the grooves on the Multiline Terminal
until they snap into place.
. To remove the directory card, press the two sides of the directory card holder
inward until the tabs release and pull the holder out of the grooves.
Figure 5-47 Attaching Directory Card to Directory Card Holder
