UNIVERGE SV9100 Issue 1.2
System Hardware Manual 5 - 135
1. Connect the cord from the telephone jack to the Line In on the D
term
Cordless DECT.
2. Connect a qualified NEC digital multiline terminal to the D
term
Cordless
DECT.
Figure 5-152 Connecting Telephone Cords to the Telephone Jack
Figure 5-153 Connecting the
D
term
Cordless DECT to the Multiline Terminal
Line "OUT"
To DTH, DTR and DTL
Multiline Terminals
