Issue 1.2 UNIVERGE SV9100
2 - 18 SV9100 System Specifications
DTL-12D-1 (BK) TEL
DTL-12D-1 (WH) TEL
1,969 ft (600m) 6,562 ft (2000m)
DTL-24D-1(BK) TEL
DTL-24D-1(WH) TEL
1,969 ft (600m) 6,562 ft (2000m)
DTL-32D-1 (BK) TEL
DTL-32D-1 (WH) TEL
1,969 ft (600m) 6,562 ft (2000m)
DCL-60-1 Console*
- 1,969 ft (600m)
* An AC Adapter is required.
Table 2-13 DT400 Series Loop Resistance and Cable Length
Terminal or Adapter
By Twisted 1-Pair
Cable (without
AC Adapter)
24 AWG
By Twisted 1-Pair
Cable (with AC
Adapter)
24 AWG
DTZ-2E-3 (BK) TEL
1,969 ft (600m) 6,562 ft (2000m)
DTZ-6DE-3 (BK) TEL
1,969 ft (600m) 6,562 ft (2000m)
DTZ-8LD-3 (BK) TEL
DTZ-8LD-3 (WH) TEL
1,969 ft (600m) 6,562 ft (2000m)
DTZ-12D-3 (BK) TEL
DTZ-12D-3 (WH) TEL
1,969 ft (600m) 6,562 ft (2000m)
DTZ-24D-3(BK) TEL
DTZ-24D-3(WH) TEL
1,969 ft (600m) 6,562 ft (2000m)
DCZ-60-3 Console*
- 1,969 ft (600m)
* An AC Adapter is required.
Table 2-14 DT700 Series Loop Resistance and Cable Length
Terminal or Adapter Ethernet Cable
ITL-2E-1 (BK) TEL
Cat 5/Cat 6 Ethernet
328.1 ft (100m)
ITL-6DE-1 (BK) TEL
Cat 5/Cat 6 Ethernet
328.1 ft (100m)
ITL-8LDE-1 (BK) TEL
Cat 5/Cat 6 Ethernet
328.1 ft (100m)
Table 2-12 DT300 Series Loop Resistance and Cable Length (Continued)
Terminal or Adapter
By Twisted 1-Pair
Cable (without
AC Adapter)
24 AWG
By Twisted 1-Pair
Cable (with AC
Adapter)
24 AWG
