・ Wire range for field wiring terminals are marked adjacent to the terminal, on the wiring diagram
or instruction manual.
Table 4: Acceptable lead diameter
Wire Range（AWG）
Model No.
Input Output
All Models 18 19
Others
・ Solid state motor overload protection level of 115 [%] of FLA is provided in each model.
・ Integral solid state short circuit protection does not provide branch circuit protection. Branch
circuit protection must be provided in accordance with the National Electrical Code and any
additional local codes.
！
Caution : - Risk of Electric Shock- Capacitor discharge time is at least 5 [min]
To Next Page
