7.1.7. Jogging: JOG
Jogging Direction: DIR
 This input starts a jogging operation.
Table 7-11: Signal logic of the input JOG Table 7-12:Signal logic of the input DIR
Logic Description Logic Description
OFF
Starts decelerating.
OFF
Plus direction
ON
Start jogging
ON
Minus direction
 Jogging starts when the input DIR specified the rotational direction and the input JOG is
activated.
 The Motor decelerates and stops when the JOG input is turned OFF in the middle of jogging.
◊ If the input JOG is turned ON again in the middle of the deceleration, the Motor keeps
decelerating and stops once. Then the input JOG activates again after the Motor
stopped.
 If the input DIR is altered in the middle of jogging, the Motor starts to move in the opposite
direction after it stopped.
◊ If the input DIR is altered in the middle decelerating, the Motor stops anyway, then the
input JOG activates again.
 Different from other positioning operations, the jogging operation does not complete by the
activation of the output IPOS (In-position). Check the completion of a jogging via the input
BUSY (In-operation).
 Refer to “6.3.4. Jogging” for the procedure of jogging.
