NSK Megatorque PS Series User Manual

— 7-30 —
7.3.2. Alarm Monitor
 Identifies the alarm and the warning currently occurring.
◊ Refer to “11. Alarm and Warning” for details.
1) Activates the input TA (Tell alarm status).
:
T
A
F3>Hardware Over
Travel;_
A
ENT
T
The monitor identifies the alarm and the warning currently occurring.
No indication on the screen if no alarm is reported.
2) Every input of SP
key identifies an alarm on the next line. Scroll all alarms by the
SP
key or pause reading out by the BS key.
SP
…
SP
:
T
A
F3>Hardware Over
Travel;
F
4>Emergency Stop;
¾ The order of readout is not corresponding to the order of alarm occurrence.
7.3.2.1. Monitor All Occurring Alarms at One Time
 You can monitor all occurring alarms at a time.
◊ Input “?TA” or ”TA/RP.”
Input the BS
key to abort repetitive readout.
Figure 7-27
TA/RP
FEDCBA9876543210
0000000000000000
0000000000000000
State of alarm
Guide
0: Normal
1: Alarm
Table 7-33: Monitor by TA/RP
Guide F E D C B A 9 8 7 6 5 4 3 2 1 0
F3 (-) F3 (+) F2 (-) F2 (+)
F8 F5 P5 C5 C0 A4 A3 F1 P9 P3 P2 P1
Alarm cord
P0 A9 A7 A2 A1 A0 C4 C3 A5 F4 E9 E8 E7 E2 E0
