NSK Megatorque PS Series User Manual

— 2-8 —
2.3.3. Handy Terminal
Fig 2-11: Handy Terminal M-FHT21
86
HANDY TERMINAL
NSKNSK
Numeric keys
Code keys (superscript)
Connector
106
90
Alphabetic keys
Special code keys
3
<
2
$
1
#
-
+
5
%
4
>
8
(
7
‘
6
&
.
=
0
?
9
)
CB A FED
IH G LKJ
ON M RQP
UT S XWV
?Z Y
＊
/
,
CTRLESC SHIF
T
ENTSPBS
SHIFT : Shift key
N
o
t
e
1)
ESC : Escape key (Not used)
CTRL : Control key
Note 2)
BS : Back space key
Note 3)
SP : Space key
Note 4)
ENT : Enter key
Note 5)
Frame
LCD
195
27
Cable
Note: (1) SHIFT: Press number key while pressing the SHIFT key to enter a code key
The superscript of each numeric key may be entered.
(2) BS: Press the BS key when correcting logged in mistakes.
(3) SP: Use this key to input a blank between letters.
(4) ENT: Press the key at the end of a command or parameter setting.
