NSK Megatorque PS Series User Manual

— 2-4 —
2.2. Reference Number and Coding
2.2.1. PS Series Megatorque Motor
Fig 2-4 :Reference number coding of PS series Megatorque Motor
Megatorque Motor
PS series
M-PS 1 006 K N 002
Motor size code
K: Incorporates absolute posiiton
sensor
Motor maximum torque [N•m]
N: No brake
Design number
002: Standard
003: High-precision products
2.2.2. EDC Driver Unit for PS Series Motor
Fig 2-5: Reference number coding of EDC Driver Unit for PS series Megatorque Motor
EDC Driver Unit
M-ED
C
–
PS1006
A
B5 02
–
01
Motor model
Design serial number: 02: Standard.
03: High-precision produts
(Made to order)
Power voltage A: 200 to 230 [VAC] (single phase)
C: 100 to 115 [VAC] (single phase)
Position sensor code B: Absolute position sensor
Function: 5: Standard
C: CC-Link (Optional)
02:Connectors,fixing blackets and Engllish
manual are included
01:Connectors,fixing blackets and Japanese
manual are included
No code:Connectors,fixing blackets and manual
are not ncluded (PS/PN Series only)
2.2.3. Cable Set
Fig 2-6: Reference number coding of Cable Set for PS series Megatorque Motor
Cable Set for
Megaorque Motor
M-C 004 SCP 03
Example: 002… 2 m
004… 4 m
010…10 m
015…15 m
030…30 m
Design number
03: Stationary Cable
13: Flexible Cable
PS/PN Series and PN Series with brake
※
Cable length has to be less than 8 [m] for combinations with PN2012 or high-precision products in PS series.
2.2.4. Handy Terminal
Fig 2-7: Reference number coding of Handy terminal
Handy Terminal
M-FHT 21
Handy Terminal serial number
