8.5.3. Position Loop Dead Band
 The parameter DBP is used to specify a dead band for the deviation of position loop. The
deviation will be zeroed when it is under the set data of the parameter DBP.
 The dead band eliminates problems of positioning instability right after completion of
positioning.
Table 8-29: Position loop dead band: DBP
Parameter Function
Initial
setting
Data range Unit
Ì DBP
Sets a dead band to the position loop. 0 0 to 4 095 0.5 [pulse]
Ì: Require an entry of the password.
 The parameter DBP specifies a dead band on the position loop deviation in both sides of 0 (zero)
and zeroes the deviation that is under the DBP setting.
 In some use conditions, slight vibration may occur due minute deviation. Provision of the dead
band eliminates such slight vibration.
◊ If a dead band is specified, the repeatability of positioning accuracy will be
deteriorated by the amount of the dead band though the slight vibration may be
eliminated.
 The unit of the dead band is a half of pulse count.
(Corresponds to a half of the resolution of position sensor. Refer to “2.7. Driver Unit
Specifications” for the resolution of position sensor.)
