— 9-47 —
P MN: Monitor, Primary
Sets an item to be monitored by the monitor MON1 (Primary analog monitor).
Refer to “7.4. Analog Monitor” for details.
Category Parameter
Format
MN data
Data range 1
0
1
2
3
4
5
6
7
8
: Current velocity
: Commanded velocity
: Velocity error
: Torque command
: øU current
: Transient position command
: Residual pulses in the error counter (Zoomed)
: Residual pulses in the error counter (Normal)
: Software thermal loading
Data range 2
Command
name
: Specify a monitor name, such as “MNTV”, for monitoring.
Shipping set 0
A change of this parameter will automatically reset the parameters MNY (Monitor offset,
primary) and MNR (Monitor range, primary) in accordance with the specified monitor.
The output offset of parameter MNY is set to a value when the monitor center is set to
2.5 [V].
The output range of parameter MNR is set to a value when the maximum monitor
output is 5.0 [V].
When a parameter or a monitor name is set to “data”, the analog monitor outputs the value of
specified parameter.
P MNR: Monitor range, Primary
This parameter specifies the monitor output range of the parameter MN (Analog monitor,
primary).
Refer to “7.4.2. Customization of Monitor Data” for details.
Category Parameter
Format
MNR data
Data range Depends on the setting of parameter MN.
Shipping set 10.000
P MNY: Monitor Offset, Primary
This parameter sets the offset of a monitor output specified by the parameter MN.
Refer to “7.4.2. Customization of Monitor Data” for details.
Category Parameter
Format
MNY data
Data range Depends on the setting of parameter MN
Shipping set 0.000
