7.3.1.4. Monitor for State of Output Functions: Monitor IO3
 Monitors the application state of output functions in a line.
The readout is for the state just before the application of the output logic.
◊ The monitor is not applicable for the parameters ST (Stability timer) and GC (Output
logic) in the command PO (Edit control input).
 The code 1 indicates that the output will be detected and the code 0 indicates that the output will
not be detected.
Table 7-32: Readout pf Monotor IO3
Guide F E D C B A 9 8 7 6 5 4 3 2 1 0
TVEU TVO TVU TEO TEU ZONEB ZONEA NEARB NEARA IPOS BUSY SVST OTMA OTPA WRN DRDY
Function code
Reserved Reserved Reserved Reserved Reserved Reserved ZONEC HCMP HOME NRM OTXA TJO TJU TTO TTU TVEO
7.3.1.5. Monitor for Individual Function
 An input of F + Function name (code) of input or output is available to monitor the
application state of a specified function.
◊ For the inputs, the monitor reports how the Driver Unit recognizes the application state
of the specified function.
◊ For the outputs, the monitor reports the state just before application of the stability
timer and the output logic.
That is, the readout is the state before filtering (stability timer) the output condition.
 For an example, Figure 7-26 below illustrates a monitoring example of the state of input SVON
(Servo on). The example indicates the code 1 showing the input SVON is effective even if at all
the input SVON is a normally closed contact.
Fig 7-26: Example of function monitor
:
FSVON/RP
FSVON 1 _
State of input
0: Not effective
1: Efective
