NSK Megatorque PS Series User Manual

— 3-1 —
3. Unpacking, Installation and Wiring
3.1. Unpacking
3.1.1. Receiving Check
 Make sure you have received the following units.
1) Megatorque Motor
2) Driver Unit
3) Cable Set (Motor and Resolver cable)
3.1.2. Motor and EDC Driver Unit Combinations
！
Caution : Confirm that the reference number of the Motor and the Driver Unit on
each nameplate matches each other in the following codes: Motor
series and size, and maximum torque.
Fig 3-1: Indication on the nameplate of Motor
NO.
PS1-11001
MODEL
M-PS 1 006 KN002
Maximum output torque
Motor size code
Motor series code
Serial number
Fig 3-2: Indication on the nameplate of Driver Unit
No. Type
PS1-11020 EDC- PS 1 006 A B 5 02-
＊＊
Maximum output torque
Motor size code
Moter series code
Serial No.
(This part is blank depending
on some version.)
