NSK Megatorque PS Series User Manual

— 8-2 —
8.1.1. Function of Control Input
 You may set function, port polarity and filter to each control input port. This function permits
you to change the preset input port function to other function, or to switch to one of extended
functions.
◊ When you assign the same function to multiple input ports, the logical addition of each
input shall be the input to the Driver Unit.
(If one of the ports is activated, its function becomes effective.)
◊ When setting an input function that is not included in the shipping set, you must
interchange it with a preset function. For example, you may set it to one of the inputs
of PRG0 to PRG7 if you do not use all of 256 program channels.
Table 8-1: Input ports of the CN2 connector and assigned functions
Shipping set
Pin
No.
Port
No.
Input
code
Polarity
Signal name Function
Logic
(shipping set)
3 PI0 EMST
Normally
closed
Emergency stop
Shuts down operation and the
Motor stops with dynamic brake.
OFF: Emergency stop
ON: Normal
4 PI1 ACLR
Normally
open
Alarm clear Clears warning.
OFF → ON: Alarm clear
5 PI2 OTP
Normally
closed
Over travel limit, +
Prohibits the rotation in CW
direction.
OFF: Activated.
ON: Not activated.
6 PI3 OTM
Normally
closed
Over travel limit, –
Prohibits the rotation in the CCW
direction.
OFF: Activated.
ON: Not activated.
7 PI4 SVON
Normally
open
Servo on Actives the Motor servo.
OFF: Servo off
ON: Servo on
8 PI5 RUN
Normally
open
Program start
Starts program operation
specified by the PRG inputs.
OFF → ON: Starts program
9 PI6 STP
Normally
open
Stop
Stops operation and execution of
programs.
OFF: Operation granted.
ON: Decelerates. Prohibit
operation
11 PI7 PRG0
Normally
open
Internal program
channel selection 0
12 PI8 PRG1
Normally
open
Internal program
channel selection 1
13 PI9 PRG2
Normally
open
Internal program
channel selection 2
14 PI10 PRG3
Normally
open
Internal program
channel selection 3
15 PI11 PRG4
Normally
open
Internal program
channel selection 4
16 PI12 PRG5
Normally
open
Internal program
channel selection 5
17 PI13 PRG6
Normally
open
Internal program
channel selection 6
18 PI14 PRG7
Normally
open
Internal program
channel selection 7
Specifies a program channel
(channel 0 to 255) to be executed
by combination of ON and OFF
of internal program channel
selection signal 0 to 7.
OFF: 0
ON: 1
19 PI15 JOG
Normally
open
Jogging
Starts and stops jogging
operation.
OFF: Decelerates
ON: Accelerates
20 PI16 DIR
Normally
open
Jogging direction Specifies the direction of jogging.
OFF: + direction
ON: – direction
！
Caution : If your System is custom made and has special Input/Output functions,
follow its specification documents.
◊ Above function settings are the shipping set.
