NSK Megatorque PS Series User Manual

— 2-9 —
2.4. Standard Combination List
2.4.1. Motor and EDC Driver Unit Combinations
Table 2-2: Motor and EDC Driver Unit Combinations
Motor
diameter
Motor
reference number
Driver Unit
Reference number
¼¼ : code for specification
of included items.
Power
voltage[VAC]
Cable
reference number
Remarks
M-EDC-PS1006AB502-¼¼ 200 to 230
M-PS1006KN002
M-EDC-PS1006CB502-¼¼ 100 to 115
M-EDC-PS1012AB502-¼¼ 200 to 230
M-PS1012KN002
M-EDC-PS1012CB502-¼¼ 100 to 115
M-EDC-PS1018AB502-¼¼ 200 to 230
ø100
M-PS1018KN002
M-EDC-PS1018CB502-¼¼ 100 to 115
M-EDC-PS3015AB502-¼¼ 200 to 230
M-PS3015KN002
M-EDC-PS3015CB502-¼¼ 100 to 115
M-EDC-PS3030AB502-¼¼ 200 to 230
M-PS3030KN002
M-EDC-PS3030CB502-¼¼ 100 to 115
M-EDC-PS3060AB502-¼¼ 200 to 230
M-PS3060KN002
M-EDC-PS3060CB502-¼¼ 100 to 115
M-EDC-PS3090AB502-¼¼ 200 to 230
ø150
M-PS3090KN002
M-EDC-PS3090CB502-¼¼ 100 to 115
• 256 channels
for internal
program.
• Pulse train
input
(Photo coupler)
M-EDC-PS1006ABC02-¼¼ 200 to 230
M-PS1006KN002
M-EDC-PS1006CBC02-¼¼ 100 to 115
M-EDC-PS1012ABC02-¼¼ 200 to 230
M-PS1012KN002
M-EDC-PS1012CBC02-¼¼ 100 to 115
M-EDC-PS1018ABC02-¼¼ 200 to 230
ø100
M-PS1018KN002
M-EDC-PS1018CBC02-¼¼ 100 to 115
M-EDC-PS3015ABC02-¼¼ 200 to 230
M-PS3015KN002
M-EDC-PS3015CBC02-¼¼ 100 to 115
M-EDC-PS3030ABC02-¼¼ 200 to 230
M-PS3030KN002
M-EDC-PS3030CBC02-¼¼ 100 to 115
M-EDC-PS3060ABC02-¼¼ 200 to 230
M-PS3060KN002
M-EDC-PS3060CBC02-¼¼ 100 to 115
M-EDC-PS3090ABC02-¼¼ 200 to 230
ø150
M-PS3090KN002
M-EDC-PS3090CBC02-¼¼ 100 to 115
M-C0¼¼SCP03
(Fixed type cable)
M-C0¼¼SCP13
(Flexible type
cable)
¼¼: Cable length
01: 1 [m]
02: 2 [m]
03. 3 [m]
04: 4 [m]
05: 5 [m]
06: 6 [m]
07: 7 [m]
07: 7 [m]
08: 8 [m]
09: 9 [m]
10: 10 [m]
15: 15 [m]
20: 20 [m]
30: 30 [m]
• Compatible
with CC-Link
• 256 program
channels for
internal
program.
