15-10
Pulse waveform:
Î
IP: Specifies the peak current level in pulsed welding. [Set range: -50 to +50]
IB: Specifies the base current level in the pulsed welding. [Set range: -50 to
+50]
PFRQ: Specifies the pulse frequency level. [Set range: -7 to +7]
PRISE: Specifies the rise angle level of the pulse wave. [Set range: -7 to +7]
PFALL: Specifies the fall angle level of the pulse wave. [Set range: -7 to +7]
Pulse slope: Specifies switch for PRISE and PFALL parameters
(* When the connected welder does not support this parameter, set to Invalid.)
Amperage
Time
PFRQIP
IB
PFALL
PRISE
Penetration:
Î
PENET: Specifies the penetration control level based on straight polarity rate.
[Set range: 0 to +30]
To Next Page
