Philips Expression MR400 - Patient and INOP Alarms

ExpressionMR400InstructionsforUseAlarms4‐27
VitalSignValueState
Avitalsignvalueisconsidered m issing(asindicatedbythreedashes,‐‐‐)whenthevitalsignhas
producedavaluesincethemonitorwasturnedon,butcannolongerproduceavalue.Examples
ofthevaluesthat
couldbecomemissingduringnormaluse,include:
•ECGheartratevalueiftheleadsareremoved.
•SPO2valueduringNoProbe,ProbeOff,etcetera.
• Temperaturevalueiftheprobewasremoved.
•Invasivepressurevaluesifthetransducerisremoved.
WhenavaluebecomesmissingduetoanINOP,anINOPalarm
willbepresent.And,apatient
alarm—duetothemissingvalue—willbepresentaswell.Therefore,thesystemcanhavean
INOPalarm,andapatientalarm,activeatthesametimeandfromthesamecause.
WARNING
If, during use, an alarm condition listed below results in a loss of patient monitoring
capability, employ an alternate means as needed to prevent a lapse in patient monitoring;
otherwise, treatment of the patient could be delayed.
Patient and INOP Alarms
Themeasurementlabelsandabbreviationsforpressure,temperature,SpO2,CO2andanesthetic
agentalarmsareexplainedintheindividualchapters.Thefollowingtablecontainsalistingof
patientalarmsarrangedbyvitalsignorparameter.Theparametermustbeonfortherespective
alarmdetectionstobeenabled;seepage3
‐18.
Note
In the case of missing data (- - -), an alarm will occur only if a valid numeric was previously displayed but can
no longer be produced; see page 2-20 for details.
Patient Alarm From Condition Indication
Extreme Brady ECG, SPO2, P1
(or P2)
The heart rate measurement has
violated the Extreme Bradycardia
alarm setting.
Red flag in ECG alarm flag area, flashing red
heart rate numeric in the ECG VS box and in
the SPO2 VS box, red alarm light, high priority
alarm tone
Extreme Tachy ECG, SPO2, P1
(or P2)
The heart rate measurement has
violated the Extreme Tachycardia
alarm setting.
Red flag in ECG alarm flag area, flashing red
heart rate numeric in the ECG VS box and in
the SPO2 VS box, red alarm light, high priority
alarm tone
Violated heart rate
value
ECG, SPO2, P1
(or P2)
The heart rate measurement has
violated an alarm limit setting.
Flashing yellow heart rate numeric in the ECG
VS box and in the SPO2 VS box, yellow alarm
light, medium priority alarm tone
