ExpressionMR400Instructionsfor UseSystemOverview2‐9
wECG Module
ThewECGmoduletransmitsmeasuredECGsignalsthroughtheRF
linktotheMR400,wheretwoECGsignalscanbedisplayedandare
availableforinterfacingwiththeMRsystemcardiacgatinginput.
ThemodulealsoreceivesinformationfromtheMR400toperform
commanded tasks(forexample,leadviewandfilter
mode
selections).
wECG Module Indicators
Batteryindicatorsprovidechargestatusin dicationsforeachbatteryusedbythewECGmodule,
asdetailedinthetablebelow.
Notes
• A battery time-remaining counter is displayed by the MR400; see page 2-16 for details.
• For battery replacement details, see page 1-24.
1 Battery 1 eject button
2 Batteries
3 Battery 2 eject button
4 Battery 1 indicator
5 Battery 2 indicator
6 Network channel indicators (1–5, in this example)
7 Network selection button
8 ECG lead cable connector
4
1
5
6
7
8
2
3
wECG Battery
Indicator
Color Charge Status
None Battery not installed in battery bay 1, or the battery’s
charge is insufficient to power the module
Green Battery installed in battery bay 1 has sufficient charge
Red Battery installed in battery bay 1 has low charge
None Battery not installed in battery bay 2, or the battery’s
charge is insufficient to power the module
Green Battery installed in battery bay 2 has sufficient charge
Red Battery installed in battery bay 2 has low charge
