ExpressionMR400InstructionsforUseMonitoringSPO26‐11
Changing the SPO2 Alarm Limits
TheSPO2AlarmLimitsmenucanbeaccessedbytouchingthealarmlimitsettingsintheSPO2VS
box.
TochangetheSPO2alarmlimitsettings
1 Alarm limit settings, SPO2 VS box
2High button
3Low button
4Desat button
5SPO2 Alarm Limits menu label
6Enter button
7 Current adjustment
8 Desat alarm setting
9 Alarm limit, minimum
10 Lower alarm limit setting
11 Upper alarm limit setting
12 Alarm limit, maximum
Step Action
1 SelectthealarmlimitsettingsintheSPO2VSbox.
TheSPO2AlarmLimits
menuappears.Currentsettingsare
displayed.
2 SelecttheLow,High,orDesatbutton.
Theselectedbuttonwillbehighlightedandthecurrentadjustment
willbedisplayed.(Desatmustbeon;seepage6‐15.)
1
2
7
3456
1098 1211
