Removing Batteries from the wECG Module
Toremovebattery1fromthewECGmodule
Pressabatteryejectbutton1(item1,right).Then
graspthepartiallyejectedmodulebattery(item2)
andpulltoremoveit.
2Orientamodulebatterysothatthetipofthebatteryarrowaligns
withthetipofthebay1
arrowonthewECGmodule.Thenslidethe
modulebatteryintobay1,pressinguntilitseatscompletely.
3Orientamodulebatterysothatthetipofthebatteryarrowaligns
withthetipofthebay2arrowonthewECGmodule.Thenslidethe
modulebatteryintobay2,
pressinguntilitseatscomplete ly.
Step Action
Module battery
Bay 1 arrow
Battery arrow
Module battery
Bay 2 arrow
Battery arrow
1
2
