Zero Set
ZerosthepressuretransducerforP1(orP2).Thepressuretransducermustbezeroedbeforeuse
andatregularintervalsduringuse.(ZeroPressureChannelwillbedisplayedduringtheprocess
andDonewillbedisplayeduponcompletion.)
Tozerothepressuretransducer
SeeZeroingthePressureTransduceronpage
8‐16.
Set Label
Assignsalabeltothepressurechannelforidentificationofthetransducersite.Thelabelwill
appearintheVSboxanditwillalsodeterminethecolorusedfortheVSbox.
Thefollowingnamesandcolorsareavailable:
• Nonedisplayedinwhite.(Default)
• ABP(arterialbloodpressure)displayed
inpink.
Note
In the event ABP is chosen as the heart rate source while there are multiple pressures labeled as
ABP, the system will choose P1.
• PAP(pulmonaryarterypressure)displayedinyellow.
2Touchthemenuitemtoselect oneofthefollowingP1(orP2)
options:
ZeroSet
SetLabel
Size
HRSource
Grids
GridsSize
Format
Themenuitemappears.Thecurrentsettingishighlighted.
3 Selectthedesiredsettingfromthemenuoptions(exceptGrids,
whichisselectableon
theP1[orP2]menu):
Thesettingisentered.
4Tochangeothersettings,repeatsteps2and3.
Step Action
