Philips Expression MR400 - AGENT and GAS VS Boxes

9‐14MonitoringAgentsandGases(AGENTOption) ExpressionMR400InstructionsforUse
AGENT and GAS VS Boxes
AGENToptionmeasurementsaredisplayedinseveralareas:
• Primaryandsecondaryagentgasmeasurementsaredisplayedasnumericinformationin
theAGENTVSbox.
•N2O,O2,andMACmeasurementsaredisplayedasnumericinformationintheGASVSbox.
•CO2measurementsaredisplayedasawaveformintheVStracearea
ofthescreenandas
numericinformationintheCO2VSbox—wheredependingupontheRESP>Source
setting,CO2‐derivedrespirationinformationmayappearintheRESPVSbox.
3Withthenewwatertrappositionedsothatthesampleportisfacing
towardyou,alignthetrap’sreleasetabsto
thereleasetabslotsinthe
watertrapreceptacle.Pressthewatertrapintothewatertrap
receptacleuntilaudible“clicks” areheard asboth ofthereleasetabs
lockintothereleasetabslots.
4 Attachthesamplinglinetothesampleport.
Step Action
Release tabs
Release tab slots
Water trap receptacle
Sample port
