• Indicationsareprovidedforalossofcommunication,whichisindicatedwithin2seconds,
andanodatacondition(seepage2‐20)willbedisplayedwithin10secondsforallvitalsign
informationmissingduetoanon‐communicatingwirelessmodule.
Status Information Panel
Thestatusinformationpanelprovideswirelesscommunicationandpowerdetails,includingthe
chargelevelofallconnectedbatteries.
Toopenthestatusinformationpanel
Selectthetitlearea(1,below)onthestatusinformationpane.
1 Indicates that no communication is occurring between the MR400
and a wireless module (wECG in this example), or between the
MR400 and the IP5.
2 Indicates a status warning when a communication error between
the MR400 and a wireless module, or between the MR400 and an
IP5 is detected.
