ExpressionMR400Instructionsfor UseSystemOverview2‐1
CHAPTER 2
System Overview
TheMR400isdesignedtoprovidemulti‐vitalsignpatientmonitoringandMRIgatingcapabilityin
theMRIenvironmentwhileincloseproximitytoanMRIscannermagnet.Themonitoring
capabilitiesoftheMR400canbeconfiguredtomeettheneedsofawidespectrumofpatients
fromneonatetoadult.
Everyparametercanbeaccessedandadjustedfortheuniqueconditionof
eachpatient.TheMR400accommodatesspecificmonitoringneeds,including:
•Adult,pediatricand neonatalpatients
•Criticallyillpatients
•Patientundergoingsedation
•PatienttransportwithintheMRenvironment
• Interventionalprocedures
•Cardiacgating
Note
We recommend the establishment of a program for supervision appropriate to the classes and
types of patients, and that all patients should receive at least routine monitoring when the MR400
is in use.
System Parameters
TheMR400simultaneouslyprocessesanddisplaysmultipleparameters,waveforms,
measurementnumericvaluesandalarms.Allpatientinformationisprovidedonthetouch
screen.AfullyequippedMR400includesmonitoringforthefollowingparameters:
• Electrocardiogram(ECG),dualchannel
•Heartrate(HR)
•Bloodoxygensaturation/pulseoximetry(S PO2)
•End‐tidalandfractionalinspiredCO2(EtCO2
andFiCO2)
•Invasivebloodpressur e(P1and P2)
•Anestheticagents(AGENT)
•FractionalinspiredO2(FiO2),andend‐tidalandfractionalinspiredN2O(EtN2OandFiN2O)
• Temperature(TEMP)
