ExpressionMR400InstructionsforUse MonitoringInvasiveBloodPressure8‐27

Thefollowingoptionsareavailable:

•Offnogridisdisplayed.(Default)

• Ondisplaysascaledgrid(alsoseeGridsSize,below).

Tocontrolthedisplayfunctionforthepressuregrid

Grids Size

SetsthescalesizewhenGridsison(seeGrids,above).

Thefollowingoptionsareavailable:

•40mmHg

•75mmHg

•100mmHg

• 150mmHg(Default)

•200mmHg

•250mmHg

Grid

Grids Size

Step Action

1 SelecttheP1(orP2)VSbox.

TheP1menu(ortheP2menu)appears.Currentsettingsare

displayed.

2LocateGridsandselectthedesiredsetting:

Off

Thesettingisentered.
