5‐6MonitoringECGExpressionMR400InstructionsforUse
Thetablebelowhighlightstherecom mendedusesofECGleadcablesandQuadtrodeelectrodes.
ECG Lead Cables and Quadtrode Electrodes - Recommended Pairings
CV ECG lead cable CV Quadtrode Electrode
Purpose:
• For patients weighing more than 10 kg (22 pounds)
• Best for female and overweight patients (that is, in situations where placement
would be difficult using the standard Quadtrode electrode)
Version and Part Number:
AAMI: REF 989803193721
IEC: REF 989803193751
Part Number:
REF 989803179041
Standard ECG lead cable
Quadtrode Electrode
(standard)
Purpose:
• For patients weighing more than 10 kg (22 pounds)
• Quick application
Version and Part Number:
AAMI: REF 989803193731
IEC: REF 989803193761
Part Number:
REF 989803179031
Neonatal ECG lead cable Neonatal (Neo)
Quadtrode Electrode
Purpose:
• For infants weighing less than 10 kg (22 pounds)
• Quick application
Version and Part Number:
AAMI: REF 989803193741
IEC: REF 989803193771
Part Number:
REF 989803179051
