14‐14MaintenanceandTroubleshooting ExpressionMR400InstructionsforUse

ToreplacetheO

2sensor.

Step Action

1TurnofftheMR400.

2Ensurethatanygassamplinglinehasbeendisconnectedfromthe

watertraponthepatientconnectionpanel.

3 Removethetwoscrewsthatsecuretheservicepanelcovertothe

backoftheWPUandthenremovetheservicepanelcover.

4Locatethesensortooland

theO2sensorport.

5PlacethesensortoolintotheslotintheO2sensor,thenturnthe

sensorcounterclockwiseuntilitdisengagesfromthesensorport.

Screws

Service panel

cover

O2 sensor

O2 tool

Slot
