A‐18Specifications ExpressionMR400InstructionsforUse

Cannula,Infant Halothane—

Systemresponse:15.95seconds

Risetime:8.63seconds

Enflurane—

Systemresponse:11.98seconds

Risetime:4.75seconds

Isoflurane—

Systemresponse:9.26seconds

Risetime:1.70seconds

Sevoflurane—

Systemresponse:6.48seconds

Risetime:0.62seconds

Desflurane—

Systemresponse:6.47seco nds

Risetime:0.61seconds

Oxygen—

Systemresponse:8.61

seconds

Risetime:1.13seconds

Nitrousoxide—

Systemresponse:7.95seconds

Risetime:0.72seconds

CO2—

Systemresponse:6.51seconds

Risetime:0.48seconds

AGENT (Optional)
