ExpressionMR400InstructionsforUse GatingFeatureD‐3
7 Proceedaccordingtothetypeofgatingbeingused:
AnalogGating—ToreceivetheanalogECGgatingwaveform
throughtheMR400,ensurethatallofthefollowingconditions
havebeenmet:
•ThecorrectgatingcableisinstalledbetweentheMR400and
the
MRsystem;
•ThesystemiscommunicatingwiththewECGmodule;
•ThewECGmoduleisproperlyattachedtothepatient;and,
• LeadFaildoesnotexistforthemeasuredECGsignal.
DigitalGating—To receivethedigital ECGgatingpulsefromthe
MR400,ensurethatallofthefollowingconditions
havebeenmet:
•ThecorrectgatingcableisinstalledbetweentheMR400and
theMRsystem;
•ThesystemiscommunicatingwiththewECGmodule;
•ThewECGmoduleisproperlyattachedtothepatient;
• LeadFaildoesnotexistforthemeasuredECGsignal;
•TheECGparameterhasbeenactivatedinthemenusystem;

and,
•TheECGsignalhasbeenselectedasthedigitalpulsesource,
asfollows:
a. SelecttheECGVSbox.
b. SelectGatingSource.
c. Select ECG.
Step Action
