145
Pressing
key causes returning to the co
ntrol process in progress.
Pressing
key causes moving to displaying a list of co
mpleted
weighments:
In order to return to the control pro
cess in progress press
key.
•
Change of the workspace
Pressing
key causes displ
aying the workspace in a form of chart with
measurement results:
144
146
