Remote Commands
R&S
®
FSW
873User Manual 1173.9411.02 ─ 43
Parameters:
<Spacing> numeric value in Hz
*RST: 2.5 MHz
Default unit: HZ
Example:
SENS:POW:ACH:SPAC:GAP2 5MHZ
Manual operation: See "Gap Channel Spacing" on page 191
Manual (Asymmetrical) Configuration
The following commands are only available for asymmetrical (manual) configuration of
gap channels (see [SENSe:]POWer:ACHannel:GAP<gap>:MODE on page 867).
CALCulate<n>:LIMit<li>:ACPower:GAP<gap>:MANual:LOWer:ABSolute............................ 873
CALCulate<n>:LIMit<li>:ACPower:GAP<gap>:MANual:LOWer:ABSolute:STATe.................. 874
CALCulate<n>:LIMit<li>:ACPower:GAP<gap>:MANual:LOWer:ACLR[:RELative]................. 875
CALCulate<n>:LIMit<li>:ACPower:GAP<gap>:MANual:LOWer:ACLR[:RELative]:STATe....... 875
CALCulate<n>:LIMit<li>:ACPower:GAP<gap>:MANual:LOWer[:CACLr][:RELative]...............876
CALCulate<n>:LIMit<li>:ACPower:GAP<gap>:MANual:LOWer[:CACLr][:RELative]:STATe.... 877
CALCulate<n>:LIMit<li>:ACPower:GAP<gap>:MANual:UPPer:ABSolute............................. 877
CALCulate<n>:LIMit<li>:ACPower:GAP<gap>:MANual:UPPer:ABSolute:STATe...................878
CALCulate<n>:LIMit<li>:ACPower:GAP<gap>:MANual:UPPer:ACLR[:RELative].................. 879
CALCulate<n>:LIMit<li>:ACPower:GAP<gap>:MANual:UPPer:ACLR[:RELative]:STATe........879
CALCulate<n>:LIMit<li>:ACPower:GAP<gap>:MANual:UPPer[:CACLr][:RELative]............... 880
CALCulate<n>:LIMit<li>:ACPower:GAP<gap>:MANual:UPPer[:CACLr][:RELative]:STATe..... 880
[SENSe:]POWer:ACHannel:BWIDth:GAP<gap>:MANual:LOWer........................................ 881
[SENSe:]POWer:ACHannel:BANDwidth:GAP<gap>:MANual:LOWer...................................881
[SENSe:]POWer:ACHannel:BWIDth:GAP<gap>:MANual:UPPer.........................................882
[SENSe:]POWer:ACHannel:BANDwidth:GAP<gap>:MANual:UPPer................................... 882
[SENSe:]POWer:ACHannel:FILTer[:STATe]:GAP<gap>:MANual:LOWer.............................. 882
[SENSe:]POWer:ACHannel:FILTer[:STATe]:GAP<gap>:MANual:UPPer............................... 883
[SENSe:]POWer:ACHannel:FILTer:ALPHa:GAP<gap>:MANual:LOWer............................... 883
[SENSe:]POWer:ACHannel:FILTer:ALPHa:GAP<gap>:MANual:UPPer................................884
[SENSe:]POWer:ACHannel:GAP<gap>:MANual:CHANnel:COUNt:LOWer...........................884
[SENSe:]POWer:ACHannel:GAP<gap>:MANual:CHANnel:COUNt:UPPer........................... 885
[SENSe:]POWer:ACHannel:SPACing:GAP<gap>:MANual:LOWer...................................... 885
[SENSe:]POWer:ACHannel:SPACing:GAP<gap>:MANual:UPPer....................................... 886
CALCulate<n>:LIMit<li>:ACPower:GAP<gap>:MANual:LOWer:ABSolute
<SBGaps>, <Limit>
CALCulate<n>:LIMit<li>:ACPower:GAP<gap>:MANual:LOWer:ABSolute?
<SBGaps>
This command defines the absolute limit of the specified lower gap (CACLR) channel.
If you define both an absolute limit and a relative limit, the R&S FSW uses the lower
value for the limit check.
Suffix:
<n>
.
irrelevant
<li> irrelevant
