RL78/G15 CHAPTER 6 TIMER ARRAY UNIT
R01UH0959EJ0110 Rev.1.10 Page 254 of 765
Mar 7, 2023
Figure 6-59. Operation Procedure When Input Signal High-/Low-Level Width Measurement Function Is Used
Software Operation Hardware Status
TAU
default
setting
Power-off status
(Clock supply is stopped and writing to each register
is disabled.)
Sets the TAUmEN bit of peripheral enable register 0
(PER0) to 1.
Power-on status. Each channel stops operating.
(Clock supply is started and writing to each register is
enabled.)
Sets timer clock select register m (TPSm).
Determines clock frequencies of CKm0 to CKm3.
Channel
default
setting
Sets the corresponding bit of the noise filter enable
register 1 (NFEN1) to 0 (off) or 1 (on).
Sets timer mode register mn (TMRmn) (determines
operation mode of channel).
Clears the TOEmn bit to 0 and stops operation of
TOmn.
Channel stops operating.
(Clock is supplied and some power is consumed.)
Operation is resumed.
Operation
start
Sets the TSmn bit to 1.
The TSmn bit automatically returns to 0 because it
is a trigger bit.
TEmn = 1, and the TImn pin start edge detection wait
status is set.
Detects the TImn pin input count start valid edge.
Clears timer count register mn (TCRmn) to 0000H
and starts counting up.
During
operation
The TDRmn register can always be read.
The TCRmn register can always be read.
The TSRmn register can always be read.
Set values of the TMRmn register, TOMmn, TOLmn,
TOmn, and TOEmn bits cannot be changed.
When the TImn pin start edge is detected, the counter
(TCRmn) counts up from 0000H. If a capture edge of
the TImn pin is detected, the count value is
transferred to timer data register mn (TDRmn) and
INTTMmn is generated.
If an overflow occurs at this time, the OVF bit of timer
status register mn (TSRmn) is set; if an overflow does
not occur, the OVF bit is cleared. The TCRmn register
stops the count operation until the next TImn pin start
edge is detected.
After that, the above operation is repeated.
Operation
stop
The TTmn bit is set to 1.
The TTmn bit automatically returns to 0 because it
is a trigger bit.
TEmn = 0, and count operation stops.
The TCRmn register holds count value and stops.
The OVF bit of the TSRmn register is also held.
TAU stop
The TAUmEN bit of the PER0 register is cleared
to 0.
Power-off status
All circuits are initialized and SFR of each channel
is also initialized.
Remark m: Unit number (m = 0), n: Channel number (n = 0 to 7)
