6.2.1 Timer count register mn (TCRmn)
The TCRmn register is a 16-bit read-only register and is used to count clocks.
The value of this counter is incremented or decremented in synchronization with the rising edge of a count clock.
Whether the counter is incremented or decremented depends on the operation mode that is selected by the MDmn3 to
MDmn0 bits of timer mode register mn (TMRmn) (refer to 6.3.3 Timer mode register mn (TMRmn)).
Figure 6-6. Format of Timer Count Register mn (TCRmn)
Address: F0180H, F0181H (TCR00) to F018EH, F018FH (TCR07), F01C0H, F01C1H (TCR10) to F01CEH, F01CFH (TCR17)
After reset: FFFFH R
F0181H (TCR00) F0180H (TCR00)
Symbol 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
TCRmn
Remark m: Unit number (m = 0), n: Channel number (n = 0 to 7)
The count value can be read by reading timer count register mn (TCRmn).
The count value is set to FFFFH in the following cases.
●
When the reset signal is generated
●
When the TAUmEN bit of peripheral enable register 0 (PER0) is cleared
●
When counting of the slave channel has been completed in the PWM output mode
●
When counting of the slave channel has been completed in the delay count mode
●
When counting of the master/slave channel has been completed in the one-shot pulse output mode
●
When counting of the slave channel has been completed in the multiple PWM output mode
The count value is cleared to 0000H in the following cases.
●
When the start trigger is input in the capture mode
●
When capturing has been completed in the capture mode
Caution The count value is not captured to timer data register mn (TDRmn) even when the TCRmn register is
read.
