RL78/G15 CHAPTER 14 INTERRUPT FUNCTIONS

R01UH0959EJ0110 Rev.1.10 Page 605 of 765

Mar 7, 2023

14.3 Registers Controlling Interrupt Functions

The following 6 types of registers are used to control the interrupt functions.

 Interrupt request flag registers (IF0L, IF0H, IF1L, IF1H)

 Interrupt mask flag registers (MK0L, MK0H, MK1L, MK1H)

 Priority specification flag registers (PR00L, PR00H, PR01L, PR01H, PR10L, PR10H, PR11L, PR11H)

 External interrupt rising edge enable register (EGP0)

 External interrupt falling edge enable register (EGN0)

 Program status word (PSW)

Table 14-2 shows a list of interrupt request flags, interrupt mask flags, and priority specification flags corresponding to

interrupt request sources.

Table 14-2. Flags Corresponding to Interrupt Request Sources (1/2)

Interrupt Source Interrupt Request Flag Interrupt Mask Flag Priority Specification Flag

20-pin

16-pin

10-pin

8-pin

INTWDTI WDTIIF IF0L WDTIMK MK0L WDTIPR0, WDTIPR1 PR00L,

PR10L

   

INTP0 PIF0 PMK0 PPR00, PPR10    

INTP1 PIF1 PMK1 PPR01, PPR11    

INTP2 PIF2 PMK2 PPR02, PPR12    

INTP3 PIF3 PMK3 PPR03, PPR13    

INTP4 PIF4 PMK4 PPR04, PPR14    

INTP5 PIF5 PMK5 PPR05, PPR15    

INTST0

Note 1

STIF0

Note 1

STMK0

Note 1

STPR00, STPR10

Note 1

   

INTCSI00

Note 1

CSIIF00

Note 1

CSIMK00

Note 1

CSIPR000, CSIPR100

Note 1

   

INTIIC00

Note 1

IICIF00

Note 1

IICMK00

Note 1

IICPR000, IICPR100

Note 1

   

INTSR0

Note 2

SRIF0

Note 2

IF0H SRMK0

Note 2

MK0H SRPR00, SRPR10

Note 2

PR00H,

PR10H

   

INTCSI01

Note 2

CSIIF01

Note 2

CSIMK01

Note 2

CSIPR001, CSIPR101

Note 2

   

INTIIC01

Note 2

IICIF01

Note 2

IICMK01

Note 2

IICPR001, IICPR101

Note 2

   

INTSRE0 SREIF0 SREMK0 SREPR00, SREPR10    

INTTM01H TMIF01H TMMK01H TMPR001H, TMPR101H    

INTTM00 TMIF00 TMMK00 TMPR000, TMPR100    

INTTM01 TMIF01 TMMK01 TMPR001, TMPR101    

INTAD ADIF ADMK ADPR0, ADPR1    

INTP6 PIF6 PMK6 PPR06, PPR16    —

INTP7 PIF7 PMK7 PPR07, PPR17    —
