RL78/G15 CHAPTER 10 A/D CONVERTER

R01UH0959EJ0110 Rev.1.10 Page 326 of 765

Mar 7, 2023

10.3.3 A/D converter mode register 2 (ADM2)

This register is used to set the resolution of the A/D converter.

The ADM2 register can be set by a 1-bit or 8-bit memory manipulation instruction.

Reset signal generation clears this register to 00H.

Figure 10-6. Format of A/D Converter Mode Register 2 (ADM2)

Address: F0010H After reset: 00H R/W

Symbol 7 6 5 4 3 2 1

□

ADM2 0 0 0 0 0 0 0 ADTYP

ADTYP Selection of the A/D conversion resolution

0 10-bit resolution

1 8-bit resolution

Caution Only rewrite the value of the ADM2 register while conversion is stopped (ADCS = 0, ADCE = 0).
