RL78/G15 CHAPTER 3 CPU ARCHITECTURE

R01UH0959EJ0110 Rev.1.10 Page 81 of 765

Mar 7, 2023

3.5 Addressing for Processing Data Addresses

3.5.1 Implied addressing

[Function]

Instructions for accessing registers (such as accumulators) that have special functions are directly specified with the

instruction word, without using any register specification field in the instruction word.

[Operand format]

Implied addressing can be applied only to MULU X.

Figure 3-15. Outline of Implied Addressing

Instruction code

A register

OP-code

Memory (register area)
