RL78/G15 CHAPTER 23 ELECTRICAL SPECIFICATIONS (T

= −40 to +85°C)

R01UH0959EJ0110 Rev.1.10 Page 719 of 765

Mar 7, 2023

23.5 Serial Interface Characteristics

AC Timing Test Points

Test points

23.5.1 Serial array unit

(1) UART mode

= −40 to +85°C, 2.4 V ≤ V

≤ 5.5 V, V

= 0 V]

Item Symbol Condition MIN. TYP. MAX. Unit

Transfer rate f

MCK

/6 bps

Theoretical value of the maximum

transfer rate

CLK

= f

MCK

= 16 MHz

2.6 Mbps

UART mode connection diagram

RL78

microcontroller

User device

TxD0

RxD0

UART mode bit width (reference)

Baud rate error tolerance

High-/low-bit width

1/Transfer rate

TxD0

RxD0

Remark f

MCK

: Serial array unit operation clock frequency

(Operation clock to be set by serial clock select register 0 (SPS0) and the CKS0n bit of serial mode register

0n (SMR0n). n: Channel number (n = 0, 1))
