RL78/G15 CHAPTER 19 FLASH MEMORY

R01UH0959EJ0110 Rev.1.10 Page 665 of 765

Mar 7, 2023

19.4 Serial Programming Method

19.4.1 Serial programming procedure

The following figure illustrates a flow for rewriting the code flash memory through serial programming.

Figure 19-6. Code Flash Memory Manipulation Procedure

Yes

Start

End

Flash memory programming mode is set

Manipulate code flash memory

End?

Controlling TOOL0 pin and

RESET pin

For the flash memory programming mode, see 19.4.2 Flash memory programming mode.
