19.6.1.4 Flash programming mode control register (FLPMC)
The FLPMC register sets the flash memory to the self-programming mode.
The FLPMC register can be set by an 8-bit memory manipulation instruction.
This register is set to 08H following a reset.
Figure 19-11. Format of Flash Programming Mode Control Register (FLPMC)
Address: F00C0H After reset: 08H R/W
Symbol 7 6 5 4 3 2 1 0
FLPMC 0 0 SELDFL 0 FWEDIS 0 FLSPM 0
SELDFL Flash programming area selection
0 Selects the code flash area.
1 Selects the data flash area.
FWEDIS Software control over enabling or disabling erasure and programming of the flash memory
Note 1
0 Enables programming and erasure.
1 Disables programming and erasure.
FLSPM Flash programming mode selection
Note 1
0 The flash memory is in the read mode (normal mode).
1 The flash memory is in the self-programming mode.
Note 1. Be sure to keep the value of this bit at 0 until erasure or programming of the flash memory is completed.
