RL78/G15 CHAPTER 18 OPTION BYTE

R01UH0959EJ0110 Rev.1.10 Page 652 of 765

Mar 7, 2023

18.3 Format of On-chip Debug Option Byte

The format of on-chip debug option byte is shown below.

Figure 18-4. Format of On-chip Debug Option Byte (000C3H)

Address: 000C3H

7 6 5 4 3 2 1 0

OCDENSET 0 0 0 0 1 0 1

OCDENSET Control of on-chip debug operation

0 Disables on-chip debug operation.

1 Enables on-chip debugging.

Note 1

Note 1. Does not erase data of flash memory in case of failures in authenticating on-chip debug security ID.

Caution Bit 7 (OCDENSET) can only be specified a value.

Be sure to set 0000101B to bits 6 to 0.

Remark The value on bits 3 and 1 will be written over when the on-chip debug function is in use and thus it will

become unstable after the setting. However, be sure to set the default values (0, 1, and 0) to bits 3 to 1 at

setting.
