RL78/G15 CHAPTER 6 TIMER ARRAY UNIT
R01UH0959EJ0110 Rev.1.10 Page 195 of 765
Mar 7, 2023
6.3.9 Timer output register m (TOm)
The TOm register is a buffer register of timer output of each channel.
The value of each bit in this register is output from the timer output pin (TOmn) of each channel.
The TOmn bit on this register can be rewritten by software only when timer output is disabled (TOEmn = 0). When timer
output is enabled (TOEmn = 1), rewriting this register by software is ignored, and the value is changed only by the timer
operation.
To use the TO0n alternate pin as a port function pin, set the corresponding TOmn bit to “0”.
The TOm register can be set by a 16-bit memory manipulation instruction.
The lower 8 bits of the TOm register can be set with an 8-bit memory manipulation instruction with TOmL.
Reset signal generation clears this register to 0000H.
Figure 6-17. Format of Timer Output register m (TOm)
Address: F01B8H, F01B9H (TO0) After reset: 0000H R/W
Symbol 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
TOm 0 0 0 0 0 0 0 0 TOm7 TOm6
TOm5
TOm4
TOm3
TOm2
TOm1
TOm0
TOmn Timer output of channel n
0 Timer output value is “0”.
1 Timer output value is “1”.
Caution Be sure to clear bits 15 to 8 to 0.
Remark m: Unit number (m = 0), n: Channel number (n = 0 to 7)
