6.3.12 Input switch control register (ISC)
The ISC register is used to implement UART0 baud rate correction by using channel 1 in association with the serial array
unit.
When the ISC1 bit is set to 1, the input signal of the serial data input (RxD0) pin is selected as a timer input.
The ISC register can be set by a 1-bit or 8-bit memory manipulation instruction.
Reset signal generation clears this register to 00H.
Figure 6-20. Format of Input Switch Control Register (ISC)
Address: F0073H After reset: 00H R/W
Symbol 7 6 5 4 3 2 1 0
ISC 0 0 0 0 0 0 ISC1 ISC0
ISC1 Switching channel 1 input of timer array unit
0 Uses the input signal of the TI01 pin as a timer input (normal operation).
1
Uses the input signal of the RxD0 pin as a timer input (detects the wakeup signal and measures the
pulse width for baud rate correction).
ISC0 Switching external interrupt (INTP0) input
0 Uses the input signal of the INTP0 pin as an external interrupt (normal operation).
1 Uses the input signal of the RxD0 pin as an external interrupt (wakeup signal detection).
Caution Be sure to clear bits 7 to 2 to 0.
