RL78/G15 CHAPTER 6 TIMER ARRAY UNIT
R01UH0959EJ0110 Rev.1.10 Page 191 of 765
Mar 7, 2023
6.3.6 Timer channel start register m (TSm)
The TSm register is a trigger register that is used to initialize timer count register mn (TCRmn) and start the counting
operation of each channel.
When a bit of this register is set to 1, the corresponding bit of timer channel enable status register m (TEm) is set to 1.
The TSmn, TSHm1, TSHm3 bits are immediately cleared when operation is enabled (TEmn, TEHm1, TEHm3 = 1),
because they are trigger bits.
The TSm register can be set by a 16-bit memory manipulation instruction.
The lower 8 bits of the TSm register can be set with a 1-bit or 8-bit memory manipulation instruction with TSmL.
Reset signal generation clears this register to 0000H.
Figure 6-14. Format of Timer Channel Start register m (TSm)
Address: F01B2H, F01B3H (TS0) After reset: 0000H R/W
Symbol 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
TSm 0 0 0 0
TSHm
3
0
TSHm
1
0 TSm7 TSm6 TSm5
TSm4 TSm3
TSm2 TSm1
TSm0
TSHm3 Trigger to enable operation (start operation) of the higher 8-bit timer when channel 3 is in the 8-bit timer mode
0 No trigger operation
1 The TEHm3 bit is set to 1 and the count operation becomes enabled.
The TCRm3 register count operation start in the interval timer mode in the count operation enabled state (see
Table 6-6 in 6.5.2 Start timing of counter).
TSHm1 Trigger to enable operation (start operation) of the higher 8-bit timer when channel 1 is in the 8-bit timer mode
0 No trigger operation
1 The TEHm1 bit is set to 1 and the count operation becomes enabled.
The TCRm1 register count operation start in the interval timer mode in the count operation enabled state (see
Table 6-6 in 6.5.2 Start timing of counter).
TSmn Operation enable (start) trigger of channel n
0 No trigger operation
1 The TEmn bit is set to 1 and the count operation becomes enabled.
The TCRmn register count operation start in the count operation enabled state varies depending on each
operation mode (see Table 6-6 in 6.5.2 Start timing of counter).
This bit is the trigger to enable operation (start operation) of the lower 8-bit timer for TSm1 and TSm3 when
channel 1 or 3 is in the 8-bit timer mode.
(Notes and Remarks are listed on the next page.)
