12.3.15 Noise filter enable register 0 (NFEN0)
The NFEN0 register is used to set whether the noise filter can be used for the input signal from the serial data input pin
to each channel.
Disable the noise filter of the pin used for simplified SPI (CSI) or simplified I
2
C communication, by clearing the
corresponding bit of this register to 0.
Enable the noise filter of the pin used for UART communication, by setting the corresponding bit of this register to 1.
When the noise filter is enabled, after synchronization is performed with the operation clock (f
MCK
) of the target channel,
2-clock match detection is performed. When the noise filter is disabled, only synchronization is performed with the
operation clock (f
MCK
) of the target channel.
The NFEN0 register can be set by a 1-bit or 8-bit memory manipulation instruction.
The value of the NFEN0 register is 00H following a reset.
Figure 12-18. Format of Noise Filter Enable Register 0 (NFEN0)
Address: F0070H After reset: 00H R/W
Symbol 7 6 5 4 3 2 1 0
NFEN0 0 0 0 0 0 0 0 SNFEN00
SNFEN00 Use of noise filter of RxD0 pin
0 Noise filter OFF
1 Noise filter ON
Set the SNFEN00 bit to 1 to use the RxD0 pin.
Clear SNFEN00 to 0 to use the other than RxD0 pin.
Caution Be sure to clear bits 7 to 1 to 0.
