RL78/G15 CHAPTER 6 TIMER ARRAY UNIT
R01UH0959EJ0110 Rev.1.10 Page 193 of 765
Mar 7, 2023
6.3.7 Timer channel stop register m (TTm)
The TTm register is a trigger register that is used to stop the counting operation of each channel.
When a bit of this register is set to 1, the corresponding bit of timer channel enable status register m (TEm) is cleared to
0. The TTmn, TTHm1, TTHm3 bits are immediately cleared when operation is stopped (TEmn, TEHm1, TEHm3 = 0),
because they are trigger bits.
The TTm register can be set by a 16-bit memory manipulation instruction.
The lower 8 bits of the TTm register can be set with a 1-bit or 8-bit memory manipulation instruction with TTmL.
Reset signal generation clears this register to 0000H.
Figure 6-15. Format of Timer Channel Stop register m (TTm)
Address: F01B4H, F01B5H (TT0) After reset: 0000H R/W
Symbol 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
TTm 0 0 0 0
0
0 TTm7 TTm6 TTm5
TTm4 TTm3
TTm2 TTm1 TTm0
TTHm3 Trigger to stop operation of the higher 8-bit timer when channel 3 is in the 8-bit timer mode
0 No trigger operation
1 TEHm3 bit is cleared to 0 and the count operation is stopped.
TTHm1 Trigger to stop operation of the higher 8-bit timer when channel 1 is in the 8-bit timer mode
0 No trigger operation
1 TEHm1 bit is cleared to 0 and the count operation is stopped.
TTmn Operation stop trigger of channel n
0 No trigger operation
1 TEmn bit is cleared to 0 and the count operation is stopped.
The TTm1 and TTm3 bits respectively trigger stoppage of operation of the lower 8-bit timers in channels 1 and 3
when these channels are in the 8-bit timer mode.
Caution Be sure to clear bits 15 to 12, 10, and 8 of the TTm register to 0.
Remark 1. When the TTm register is read, 0 is always read.
Remark 2. m: Unit number (m = 0), n: Channel number (n = 0 to 7)
