RL78/G15 CHAPTER 19 FLASH MEMORY

R01UH0959EJ0110 Rev.1.10 Page 670 of 765

Mar 7, 2023

19.6.1.1 Flash address pointer registers H and L (FLAPH, FLAPL)

The FLAPH and FLAPL registers specify the address where programming of the flash memory is to start.

The FLAPH and FLAPL registers can be set by an 8-bit memory manipulation instruction.

These registers are set to 00H following a reset.

Figure 19-8. Format of Flash Address Pointer Registers H and L (FLAPH, FLAPL)

Address: F00C3H After reset: 00H R/W

Symbol 7 6 5 4 3 2 1 0

FLAPH 0 0 0 FLAP12 FLAP11 FLAP10 FLAP9 FLAP8

Address: F00C2H After reset: 00H R/W

Symbol 7 6 5 4 3 2 1 0

FLAPL FLAP7 FLAP6 FLAP5 FLAP4 FLAP3 FLAP2 FLAP1 FLAP0
