RL78/G15 CHAPTER 6 TIMER ARRAY UNIT
R01UH0959EJ0110 Rev.1.10 Page 197 of 765
Mar 7, 2023
6.3.11 Timer output mode register m (TOMm)
The TOMm register is used to control the timer output mode of each channel.
When a channel is used for the independent channel operation function, set the corresponding bit of the channel to be
used to 0.
When a channel is used for the simultaneous channel operation function (PWM output, one-shot pulse output, multiple
PWM output, or two-channel input with one-shot pulse output), set the corresponding bit of the master channel to 0 and
the corresponding bit of the slave channel to 1.
The setting of each channel n by this register is reflected at the timing when the timer output signal is set or reset while
the timer output is enabled (TOEmn = 1).
The TOMm register can be set by a 16-bit memory manipulation instruction.
The lower 8 bits of the TOMm register can be set with an 8-bit memory manipulation instruction with TOMmL.
Reset signal generation clears this register to 0000H.
Figure 6-19. Format of Timer Output Mode register m (TOMm)
Address: F01BEH, F01BFH (TOM0) After reset: 0000H R/W
Symbol 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
TOMm 0 0 0 0 0 0 0 0
TOMm
7
TOMm
6
TOMm
5
TOMm
4
TOMm
3
TOMm
2
TOMm
1
0
TOMmn Control of timer output mode of channel n
0 Master channel output mode (to produce toggle output by timer interrupt request signal (INTTMmn))
1
Slave channel output mode
(output is set by the timer interrupt request signal (INTTMmn) of the master channel, and reset by the timer
interrupt request signal (INTTMmp) of the slave channel)
Caution Be sure to clear bits 15 to 8, and 0 to 0.
Remark m: Unit number (m = 0)
n: Channel number
n = 0 to 7 (n = 0, 2, 4, 6 for master channel)
p: Slave channel number
n < p ≤ 7
(For details of the relation between the master channel and slave channel, refer to 6.4.1 Basic rules of
simultaneous channel operation function.)
