RL78/G15 CHAPTER 23 ELECTRICAL SPECIFICATIONS (T
A
= −40 to +85°C)
R01UH0959EJ0110 Rev.1.10 Page 720 of 765
Mar 7, 2023
(2) Simplified SPI (CSI) mode (master mode, SCKp... internal clock output)
[T
A
= −40 to +85°C, 2.4 V ≤ V
DD
≤ 5.5 V, V
SS
= 0 V]
Item Symbol Condition MIN. TYP. MAX. Unit
SCKp cycle time t
KCY1
t
KCY1
≥ 4/f
CLK
2.4 V ≤ V
DD
≤ 5.5 V 250 ns
SCKp high-/low-level width t
KH1
, t
KL1
2.7 V ≤ V
DD
≤ 5.5 V
t
KCY1
/2 − 18 ns
2.4 V ≤ V
DD
≤ 5.5 V
t
KCY1
/2 − 38 ns
SIp setup time
(to SCKp ↑)
Note 1
t
SIK1
2.7 V ≤ V
DD
≤ 5.5 V
47 ns
2.4 V ≤ V
DD
≤ 5.5 V
75 ns
SIp hold time
(from SCKp ↑)
Note 1
t
KSI1
19 ns
Delay time from SCKp ↓ to SOp
output
Note 2
t
KSO1
C = 30 pF
Note 3
25 ns
Note 1. When DAP0n = 0 and CKP0n = 0, or DAP0n = 1 and CKP0n = 1. The SIp setup time becomes “to SCKp ↓”
and the SIp hold time becomes “from SCKp ↓” when DAP0n = 0 and CKP0n = 1, or DAP0n = 1 and CKP0n =
0.
Note 2. When DAP0n = 0 and CKP0n = 0, or DAP0n = 1 and CKP0n = 1. The delay time to SOp output becomes
“from SCKp ↓” when DAP0n = 0 and CKP0n = 1, or DAP0n = 1 and CKP0n = 0.
Note 3. C is the load capacitance of the SCKp and SOp output lines.
(3) Simplified SPI (CSI) mode (slave mode, SCKp... external clock input)
[T
A
= −40 to +85°C, 2.4 V ≤ V
DD
≤ 5.5V, V
SS
= 0V]
Item Symbol Condition MIN. TYP. MAX. Unit
SCKp cycle time t
KCY2
2.7 V ≤ V
DD
≤ 5.5 V
6/f
MCK
ns
2.4 V ≤ V
DD
≤ 5.5 V
6/f
MCK
and
also 500
ns
SCKp high-/low-level width t
KH2
,t
KL2
2.4 V ≤ V
DD
≤ 5.5 V
t
KCY2
/2 − 18 ns
SIp setup time
(to SCKp ↑)
Note 1
t
SIK2
2.7 V ≤ V
DD
≤ 5.5 V
1/f
MCK
+ 20 ns
2.4 V ≤ V
DD
≤ 5.5 V
1/f
MCK
+ 30 ns
SIp hold time
(from SCKp ↑)
Note 1
t
KSI2
2.4 V ≤ V
DD
≤ 5.5 V
1/f
MCK
+ 31 ns
Delay time from SCKp ↓ to SOp
output
Note 2
t
KSO2
C = 30 pF
Note 3
2.7 V ≤ V
DD
≤ 5.5 V 2/f
MCK
+ 50 ns
2.4 V ≤ V
DD
≤ 5.5 V 2/f
MCK
+ 75 ns
Note 1. When DAP0n = 0 and CKP0n = 0, or DAP0n = 1 and CKP0n = 1. The SIp setup time becomes “to SCKp ↓”
and the SIp hold time becomes “from SCKp ↓” when DAP0n = 0 and CKP0n = 1, or DAP0n = 1 and CKP0n =
0.
Note 2. When DAP0n = 0 and CKP0n = 0, or DAP0n = 1 and CKP0n = 1. The delay time to SOp output becomes
“from SCKp ↓” when DAP0n = 0 and CKP0n = 1, or DAP0n = 1 and CKP0n = 0.
Note 3. C is the load capacitance of the SOp output lines.
