RL78/G15 CHAPTER 14 INTERRUPT FUNCTIONS

R01UH0959EJ0110 Rev.1.10 Page 606 of 765

Mar 7, 2023

Table 14-2. Flags Corresponding to Interrupt Request Sources (2/2)

Interrupt Source Interrupt Request Flag Interrupt Mask Flag Priority Specification Flag

20-pin

16-pin

10-pin

8-pin

INTTM03H TMIF03H IF1L TMMK03H MK1L TMPR003H, TMPR103H PR01L,

PR11L

   

INTIICA0 IICAIF0 IICAMK0 IICAPR00, IICAPR10    

INTTM02 TMIF02 TMMK02 TMPR002, TMPR102    

INTTM03 TMIF03 TMMK03 TMPR003, TMPR103    

INTIT ITIF ITMK ITPR0, ITPR1    

INTTM04 TMIF04 TMMK04 TMPR004, TMPR104    

INTTM05 TMIF05 TMMK05 TMPR005, TMPR105    

INTTM06 TMIF06 TMMK06 TMPR006, TMPR106    

INTTM07 TMIF07 IF1H TMMK07 MK1H TMPR007, TMPR107 PR01H,

PR11H

   

INTCMP0 CMPIF0 CMPMK0 CMPPR00, CMPPR10    

INTCMP1 CMPIF1 CMPMK1 CMPPR01, CMPPR11  — — —

Note 1. If one of the interrupt sources INTST0, INTCSI00, and INTIIC00 is generated, bit 7 of the IF0L register is set

to 1. Bit 7 of the MK0L, PR00L, and PR10L registers supports these three interrupt sources.

Note 2. If one of the interrupt sources INTSR01, INTCSI01, INTIIC01 is generated, bit 0 of the IF0H register is set to

1. Bit 0 of the MK0H, PR00H, and PR10H registers supports these three interrupt sources.


