RL78/G15 CHAPTER 1 OUTLINE

R01UH0959EJ0110 Rev.1.10 Page 30 of 765

Mar 7, 2023

Table 1-5. Multiplexed Functions of 20-pin Products (2/2)

No.

I/O

Power supply,

system, clock,

debug

Analog HMI Timer Communications Interface

20LSSOP

Digital port

A/D converter

Comparator

Interrupt

function

Timer array

unit

Serial array

unit

Serial

interface IICA

19 P23 — ANI7 — (INTP6) TI04/TO04 (SCL01) —

20 P22 — ANI8 — (INTP5) TI06/TO06 (SDA01) —

Remark 1. For pin identification, see 1.4 Pin Identification.

Remark 2. Functions in parentheses can be assigned via settings in the peripheral I/O redirection register (PIOR).

Refer to Figure 4-6 Format of Peripheral I/O Redirection Registers 0 to 3 (PIOR0 to PIOR3).
